Heavy plate feeder alloy steel chain plate features and advantages
Alloy steel cast chain plate is competitive in many aspects in the application of heavy plate feeder because of its material characteristics and casting technology advantages.
1. High strength and load carrying capacity
Material properties: alloy steel by adding chromium, nickel, molybdenum, vanadium and other elements, significantly improve the strength of the matrix, so that its tensile strength and yield strength is much higher than ordinary carbon steel.
It is suitable for large bin pressure, large particle size, heavy load conveying system and other conditions that need to withstand high impact or static heavy load.
2.Excellent wear resistance
Alloy elements form hard carbides (such as Cr7C3, VC) to improve surface hardness and reduce friction loss.
The wear resistance of high chromium alloy steel can reach 3-5 times that of ordinary steel, which is suitable for long-term contact with ore, sand and other abrasives. Especially in the hard rock such as granite, iron ore, tuff and other high grinding properties of the material transportation obviously play its outstanding advantages.
3. Anti-fatigue performance
Tempering treatment (quenching + tempering) to obtain tempered sorbite structure, significantly increase the fatigue limit. Lifetime can be up to 2 times more than ordinary steel chain plate.
4. Technics predominance
Sand mold/precision casting can form the structure with holes, reinforcing bars and special-shaped profiles in one body to reduce welding stress concentration.
Through rational material selection and process design, alloy steel cast chain plate can significantly improve the reliability of equipment and reduce the comprehensive cost.
