Product description
The chain bucket elevator uses hybrid or gravity discharge to excavate and load, suitable for conveying powdery, granular, and small block bottom grinding materials with a bulk density.
Application
The chain bucket elevator is the product that has been introduced and developed by foreign advanced technology, suitable for vertical delivery of powder, granular and bulk materials, it can also improve the abrasive material, such as fly ash, slag, limestone, cement raw materials, cement clinker, cement, coal, dry clay, chemical fertilizer, grain, etc. Material temperature generally does not more than 250°.
Working principle
The chain bucket is fixed on the high-strength chain as a traction part.When equipped with deep bucket, it is suitable for conveying dry, loose and powdery, granular,massive materials which having good flowability. When equipped with shallow buckets, it is suitable for powdered and granular materials which are slightly damp, easy to agglomerate, poor flowability.
Technical parameter
Model | TH160 | TH250 | TH315 | TH400 | TH500 | TH630 | |||||||
Bucket type | Shallow | Deep | S | D | S | D | S | D | S | D | S | D | S |
Capacity(m3) | 6 | 8 | 16 | 19 | 12 | 15 | 27.5 | 32 | 43.8 | 50.5 | 71 | 95 | 106 |
Bucket width(mm) | 160 | 250 | 315 | 400 | 500 | 630 | |||||||
Bucket volume(L) | 1.34 | 1.45 | 3.3 | 3.7 | 3.3 | 3.7 | 6.5 | 7.2 | 10.3 | 11.6 | 19.6 | 30.8 | |
Bucket pitch(mm) | 400 | 400 | 198 | 500 | 500 | 680 | 500 | 680 | |||||
Chain specification | Φ14x50x7 | Φ14x50x7 | Φ18x64x7 | Φ18x64x7 | Φ22x86x7 | Φ18x64x7 | Φ22x86x7 | ||||||
Speed(m/s) | 1.25 | 1.25 | 1.25 | 1.3 | 1.3 | 1.4 | 1.4 | ||||||
